Cement High Temperature Centrifugal Fan 220V 380V Color Custom

High temperature centrifugal blower fan current component power supply system stainless steel centrifugal fan

High temperature centrifugal fan is used to transport non-corrosive, non-spontaneous combustion, the highest temperature does not exceed 700℃ of high temperature gas, the dust and hard particles contained in the medium is not more than 150mg/m³. The fan is made of two rotation directions. From the motor end, the rotation direction of the fan impeller is right rotation according to clockwise rotation, and left rotation according to counterclockwise rotation.
This series of centrifugal induced draft fan for boiler high temperature wear resistance is improved on the basis of the original Y4-73 type products, the original airfoil blade to the veneer type blades, and in the middle of the plate after front coil and reinforcing the central disk, the reinforcing the central disk consists of a 12 quick steel welding between two adjacent blades, blade working face are parts with FNM - 2 hardfacing electrode welding wear-resisting layer, Ensure the fan high efficiency, low noise, high strength, high wear resistance, prolong the service life of the fan.

The high temperature fan is suitable for conveying high temperature gas without corrosion, spontaneous combustion, and the maximum temperature does not exceed 700℃. If the dust content of the gas is large, the dust removal device with a dust removal efficiency MATCH of less than 85% should be equipped before the air inlet of the fan to improve the service life of the fan. Where the air intake conditions are equivalent, the performance of the suitable can be selected

Key Features

• Impeller diameter: 70~3500 mm
• Speed of mainshaft: 560~2900 rpm
• Pressure range: 1000~25425 Pa
• Flow range: 3297~733050 m3/h
• Air Temperature: 20~1000 Celsius degree

• Material: Stainless Steel,304.310.316.

• Efficiency: 80%-90%
