Custom Low Noise Centrifugal Fan , Industrial Exhaust Blower Fan

Single inlet centrifugal fan industrial exhaust fans forward centrifugal fan outlet flange radial centrifugal fan

Single inlet centrifugal fan impeller is welded by front disc, back disc, hub and blade.

Single air inlet: that is, there is only one air inlet of the fan. There's only one air inlet and one air outlet

Single suction centrifugal fan:

A. From the structure, the single-side intake ventilator can adopt the cantilever structure, and the transmission mode is more flexible.

B, due to the cantilever structure, the bearing requirements are high. When directly connected, the type of motor directly connected impeller should not be too large or connected with a coupling.

C, single inlet structure, according to different impeller design, can achieve higher pressure.

Used in high pressure, dust removal system, filtration system, various process systems......

The air inlet end can be directly added pipe.

Key Features

• Impeller diameter: 90~3500 mm
• Speed of mainshaft: 560~2900 rpm
• Pressure range: 3000~25425 Pa
• Flow range: 1297~43305 m3/h
• Air Temperature: 20~1000 Celsius degree

• Material: Cast Iron, Carbon Steel, Stainless Steel.

• Efficiency: 80%-90%
