Wear Resistant Centrifugal Fan Blades Carbon Steel For Cement Plant

Fan Blades Wear Resistant Layer Surfacing Treatment Special Used For Cement Plant

When using the centrifugal fan, you will find that the wear of the long-term use of the fan is very serious, and the serious wear is accompanied by the slow operation of the fan. The fan put into production is likely to lead to a decrease in output, so we should try to avoid fan wear. At this time, certain anti-wear measures must be taken:

1. Use centrifugal fan dust removal device:

Dust and other particulate matter in the environment of centrifugal fan will accelerate fan wear. Therefore, the centrifugal fan dust removal device can be used to purify the working environment of the centrifugal fan and reduce the wear of the centrifugal fan.

2, centrifugal fan blade surface and structure changes:

The surface of the centrifugal fan blade can be treated by some appropriate methods, such as spraying hard alloy, carburizing, gluing ceramic sheet, plasma surface and so on. These treatment methods can increase the surface hardness of the blade to a certain extent, so that the wear resistance of the blade is reduced by changing the surface structure of the centrifugal fan blade. Hollow blade can be changed to solid blade, blade welding with anti-wear block, blade work. The surface is machined into a serrated shape.

3. The surface of centrifugal fan is sprayed with wear-resistant coating:

This method is a simple way to prevent wear of the centrifugal fan. It is not only simple to operate, but also inexpensive. The disadvantage is that the lining of the centrifugal fan wears quickly, and it is necessary to respray the wear-resistant lining on the surface of the centrifugal fan frequently, about once every 3-5 months.

4. Anti-wear cascade before centrifugal fan:

Installing the cascade in the easy wear part of the centrifugal fan can prevent the particles from flowing to the root of the blade and the back plate, so that the concentrated wear of the particles becomes uniform wear, thereby improving the wear resistance of the impeller and extending the service life of the impeller.


Key Features

• Impeller diameter: 90~3500 mm
• Speed of mainshaft: 560~2900 rpm
• Pressure range: 3000~25425 Pa
• Flow range: 1297~83305 m3/h
• Air Temperature: 20~1000 Celsius degree

• Material: Cast Iron, Carbon Steel, Stainless Steel.

• Efficiency: 80%-90%

Please advise us the USAGE and following Parameter.Our engineering Dept will recommend the most suitable product for you.
