Product Details:
|
| Voltage: | 220/380/415/440/450v | Blade Material: | Stainless Steel,Cast Iron,Steel Plate,Q345 (16Mn) Manganese Steel |
|---|---|---|---|
| Air Volume: | 800 - 90000m3 / H | Mounting: | Free Standing,installed By Screws |
| Type: | Centrifugal Fan,Centrifugal Ventilator | After-sales Service Provided: | Engineers Available To Service Machinery Overseas,Online Support |
| Speed: | 2900 R/min | Electric Current Type: | AC |
| Application: | Air Blower,cement Plant | Warranty: | 1 Year |
| Material: | Q345/stainless/Titanium Alloy/steel,Carbon Steel /Stainless Steel,cast Iron,100% Aluminum | Color: | Customer's Requirement,Black Silver White |
| Noise: | 72dB,56-68 DB | Product Name: | 9-26 High Pressure Centrifugal Smoke Exhaust Ventilate Fan Blower,140mm Centrifugal Blower Fan,Industry Dust Collector Centrifugal Exhaust Fan Blower,High Pressure Dust Collector Centrifugal Blower With Siemens Motor,9-19 |
| Motor: | China Top Brand | Feature: | High Efficiency,Low Noise Power Saving,easy Installation,high Pressure,High Performance |
| Pressure: | High Pressure,3000~16000Pa,200~3220Pa,5335-6216 Pa,4603-4447Pa |
High Pressure Centrifugal Fan Small High Pressure Blower High Speed Blower High Performance Blower high capacity blower
The high pressure centrifugal fan is generally composed of air inlet, impeller, volute, air outlet, transmission group, base and motor.
Air inlet
The air inlet is made as a whole and installed on the side of the fan volute. The axial interface of the air inlet is streamlined, which can make the air flow into the impeller evenly, so as to reduce the flow loss and improve the efficiency of the impeller.
Impeller wheel
Impeller is the most important part of centrifugal fan, its function is to convert mechanical energy into static pressure energy and kinetic energy, impeller is usually composed of front disk, blade, back disk, shaft disk, before assembly by static and dynamic balance correction, stable operation, good air performance.
Volute shell
The volute is the channel of the air flow. The profile is usually a logarithmic spiral line, which has the function of collecting the air flow and leading to the outlet, and the volute also has
Certain pressure expansion effect.
High pressure centrifugal fans are generally used for discharging air mixtures containing wood debris, fibers and dust, as well as for material handling and other applications. It can also be used for indoor ventilation of large buildings such as factories, and high-pressure forced ventilation of boilers and forging furnaces.
The type of gas transported by the high-pressure centrifugal fan is air or other non-flammable, explosive and non-corrosive gas to steel. The gas shall not contain viscous substances, and the dust and hard particles contained shall not exceed 150mg/m³. Generally, the temperature of conveying gas shall not exceed 80℃.
Key Features
Material: Cast Iron, Carbon Steel, Stainless Steel.
Efficiency: 70%-90%
Applications
