760rpm-2900rpm High Pressure Centrifugal Blower For Industrial

High pressure centrifugal cooling fan blower with high efficiency for industrial

High pressure centrifugal fan is an model of  centrifugal fan, the working principle and centrifugal cooling fan, has been widely used in conveying material, its characteristic is belong to the small flow, high wind pressure, convulsions, air distribution effect is good, most of the manufacturers on the market at present production of series of A type and D type two kinds, A type is directly type motor drive, D type is coupling transmission.

High pressure blower fan service conditions:

1, the transmission medium requirements: the transmission medium should be non-corrosive, non-flammable and explosive, does not contain viscous substances, dust and hard particles in the medium is not greater than 150mg/m3.
2, the medium temperature: generally not more than 50℃ (maximum not more than 80℃)

Key Features

• Impeller diameter: 80~3500 mm
• Speed of mainshaft: 760~2900 rpm
• Pressure range: 9000~25425 Pa
• Flow range: 3297~43305 m3/h
• Air Temperature: 20~1000 Celsius degree

• Material: Cast Iron, Carbon Steel, Stainless Steel.

• Efficiency: 70%-90%
