Belt Drive High Pressure Centrifugal Blower 220V For Chemical Processing

Industrial Hot Air Blower High Performance Blower Belt Driven Centrifugal Fan Boiler Centrifugal Fan Roots Type Blower

High-pressure fans have the following characteristics:

1, with blowing and suction dual function, one machine dual purpose, can be used for suction, can also be used for blowing;

2, less oil or no oil operation, the output air is clean;

3. Compared with centrifugal fans and medium-pressure fans, the pressure is much higher, often more than ten times that of centrifugal fans;

4, if the pump body is the overall die-casting, and the use of shockproof installation foot pedestal, then it is also very low requirements for the installation foundation, and even can not be fixed foot pedestal can be normal operation, very convenient, but also very saving installation cost and installation cycle;

5. Compared with similar fans, its running noise is low, and ultra-silent high-pressure fans are launched:

6, maintenance-free use; Its loss parts are only two bearings, which basically do not need maintenance within the warranty period;

7, the mechanical wear of the high-pressure fan is very small, because in addition to the bearing, there is no other mechanical contact part, so the service life is of course very long, as long as it is under normal conditions of use, 3 to 5 years is no problem at all.

The use of high pressure fan:

When the high-pressure fan is running, the current consumed by the motor will increase with the increase of pressure and vacuum. If the current is too large, the contacter will jump off. In order to prevent the jump or save electricity, please increase the cross-sectional area of the air outlet as much as possible, or install the air pressure and air volume regulating valve on the suction or exhaust side.

Key Features

• Impeller diameter: 90~3500 mm
• Speed of mainshaft: 560~2900 rpm
• Pressure range: 3000~25425 Pa
• Flow range: 1297~43305 m3/h
• Air Temperature: 20~1000 Celsius degree

• Material: Cast Iron, Carbon Steel, Stainless Steel.

• Efficiency: 70%-90%
