Product Details:
|
| Voltage: | 220V/380V/440V/480V/660V | Blade Material: | Stainless Steel,Cast Iron,Steel Plate,Q345 (16Mn) Manganese Steel |
|---|---|---|---|
| Air Volume: | 800 - 90000m3 / H | Power: | 5 - 350KW |
| Warranty: | 1 Year | Color: | Customer's Requirement |
| Material: | Steel,316L,Carbon Steel /Stainless Steel,Q235 | Type: | Centrifugal Fan,Multi-wings Industrial Centrifugal Exhaust Blower Fan,centrifugal Blower,high Pressure Blower |
| Applications: | Cooling Systems | Name: | Industrial Axial Flow Fan |
| Certification: | CE, ISO 9001 | ||
| High Light: | 660V High Pressure Centrifugal Blower,Stainless Steel High Pressure Centrifugal Blower,316L Stainless Steel Centrifugal Fan |
||
G4-68 Model high volume air blower backward curved centrifugal fans and induced draft fan are suitable for the ventilation and ventilating of steam boilers below 230T /h in thermal power plants. In the absence of other special requirements, G4-68 can also be used for mine ventilation and general ventilation. Both types of fans have the advantages of high efficiency, low noise and high strength. The medium transported by the ventilator is air, and the maximum temperature does not exceed 80℃; The medium transported by the induced draft fan is flue gas, and the maximum temperature shall not exceed 250 ° C. There are 7 machine numbers from No.8 to No.16.
Key Features
Material: Cast Iron, Carbon Steel, Stainless Steel.
Efficiency: 80%-90%
Applications
Please advise us the USAGE and following Parameter.Our engineering Dept will recommend the most suitable product for you.
| Air volume/air flow | m3/h | |
| Total pressure or static pressure | Pa | |
| Medium temperature | °c | |
| Voltage | V | |
| Frequency | Hz | |
| Altitude of operation place | m |
