Energy Saving High Temperature Centrifugal Fan Blower For Cooling Systems

High Temperature Fans High Temperature Air Blower Stainless Steel Blower Special Fan Brushless Cooling Fan

This series of high temperature air blower induced draft fan for boiler high temperature wear resistance is improved on the basis of the original Y4-73 type products, the original airfoil blade to the veneer type blades, and in the middle of the plate after front coil and reinforcing the central disk, the reinforcing the central disk consists of a 12 quick steel welding between two adjacent blades, blade working face are parts with FNM - 2 hardfacing electrode welding wear-resisting layer, Ensure the fan high efficiency, low noise, high strength, high wear resistance, prolong the service life of the fan.

High temperature centrifugal fans is a newly designed high-efficiency energy-saving product, mainly used for conveying temperature of 250~400℃, dust content less than 150mg/m³

High temperature gas. Fw9-26 fan is used to transport high temperature corrosive gas. The high temperature fan has D, C, F transmission mode.
This series of high temperature fan is suitable for conveying high temperature gas without corrosion, spontaneous combustion, and the maximum temperature does not exceed 700℃. If the dust content of the gas is large, a dust removal device with a dust removal efficiency MATCH of less than 85% should be equipped before the air inlet of the fan to improve the service life of the fan. Where the air intake conditions are equivalent, the performance of the suitable can be selected. The machine number is No.5, No.6, No.9 and so on


Key Features

• Impeller diameter: 90~3500 mm
• Speed of mainshaft: 560~2900 rpm
• Pressure range: 3000~25425 Pa
• Flow range: 1297~83305 m3/h
• Air Temperature: 20~1000 Celsius degree

• Material: Cast Iron, Carbon Steel, Stainless Steel.

• Efficiency: 80%-90%

Please advise us the USAGE and following Parameter.Our engineering Dept will recommend the most suitable product for you.
