Industrial Centrifugal Fan With And Impeller Diameter Of 90-3500 Mm For Air Temperature Range Of 20-1000 Celsius Degree High Temperature Centrifugal Fan

Industrial Centrifugal Fan With And Impeller Diameter Of 90-3500 Mm For Air Temperature Range Of 20-1000 Celsius Degree High Temperature Centrifugal Fan
Industrial Centrifugal Fan With And Impeller Diameter Of 90-3500 Mm For Air Temperature Range Of 20-1000 Celsius Degree High Temperature Centrifugal Fan Industrial Centrifugal Fan With And Impeller Diameter Of 90-3500 Mm For Air Temperature Range Of 20-1000 Celsius Degree High Temperature Centrifugal Fan Industrial Centrifugal Fan With And Impeller Diameter Of 90-3500 Mm For Air Temperature Range Of 20-1000 Celsius Degree High Temperature Centrifugal Fan Industrial Centrifugal Fan With And Impeller Diameter Of 90-3500 Mm For Air Temperature Range Of 20-1000 Celsius Degree High Temperature Centrifugal Fan

Large Image :  Industrial Centrifugal Fan With And Impeller Diameter Of 90-3500 Mm For Air Temperature Range Of 20-1000 Celsius Degree High Temperature Centrifugal Fan

Product Details:
Place of Origin: China,Henan
Brand Name: ZR BLOWER
Certification: CE, ISO 9001
Model Number: ZR-HC SERIES
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: 50-50000
Packaging Details: WOODEN PACKING
Delivery Time: 5-45DAYS
Payment Terms: L/C, D/A, D/P, T/T
Supply Ability: 10000
Contact Now

Industrial Centrifugal Fan With And Impeller Diameter Of 90-3500 Mm For Air Temperature Range Of 20-1000 Celsius Degree High Temperature Centrifugal Fan

Description
Voltage: 220V/380V/440V/480V/660V Air Volume: 800 - 90000m3 / H
Power: 5 - 350KW Blade Material: Stainless Steel,Cast Iron,Steel Plate,Q345 (16Mn) Manganese Steel
Warranty: 1 Year Color: Customer's Requirement
Material: Steel,316L,Carbon Steel /Stainless Steel,Q235 Type: Centrifugal Fan,Multi-wings Industrial Centrifugal Exhaust Blower Fan,centrifugal Blower,high Pressure Blower
Applications: Cooling Systems Name: Industrial Axial Flow Fan
Certification: CE, ISO 9001 Efficiency: 85-95%
Advantage: Convenient Installation Mounting: Free Standing,installed By Screws
Drivetrain: V-belt Driven Pressure Range: 615-8302PA
Impeller Testing: Dynamic Blancing Adjusting Air Flow: 1000m3/h
Noise: Optional Motor: SIEMENS/ABB/By Your Demand
Temperature Range: Up To 500℃ Electric Current Type: AC
Service Life: ≥20000h Impellr: 540-3211 Mm
Bearing Cooling: Air Cooling Or Circulating Water Cooling Applicable Industries: Construction Works
Highlight:

high temperature centrifugal fan with impeller

,

industrial centrifugal fan for high heat

,

centrifugal fan for 1000 degree air

Industrial Centrifugal Fan With Impeller Diameter Of 90-3500 Mm For Air Temperature Range Of 20-1000°C
High-Temperature Centrifugal Fan
Definition and Core Characteristics
A high-temperature centrifugal fan is a specialized centrifugal ventilation equipment capable of operating stably in high-temperature environments ranging from 100°C to 900°C (with some special models reaching up to 1200°C). Its core principle is to convert mechanical energy into gas potential energy through a high-speed rotating impeller, enabling the transportation of high-temperature gases (such as hot air, flue gas, calcination tail gas, etc.). It is widely used in high-temperature industrial scenarios like metallurgy, building materials, and chemical engineering.
Its design needs to specifically address technical pain points caused by high temperatures:
  • Heat-resistant materials (e.g., 310S heat-resistant steel for impellers, high-temperature ceramic coatings for casings) are used to resist high-temperature erosion
  • An independent cooling system (such as air cooling or water cooling) is equipped to protect core components like motors and bearings
  • Gaps for thermal expansion and contraction are reserved to prevent component deformation due to high temperatures, ensuring long-term operational efficiency and safety
Core Characteristics
The core characteristics of high-temperature centrifugal fans revolve around "adapting to high-temperature working conditions and ensuring stable operation", with 4 key features:
1. Strong High-Temperature Resistance
Core components made of 310S heat-resistant steel or Cr25Ni20, can withstand 100-900°C (up to 1200°C for special models)
2. Structural Resistance to Thermal Deformation
Thermal expansion gaps and reinforced impeller structures reduce vibration and ensure stability
3. Targeted Cooling Protection
Independent cooling systems for motors and bearings prevent component failure
4. Adaptation to High-Temperature Gases
Optimized blade angles and flow channels ensure stable performance with low-density gases
Industrial Centrifugal Fan With And Impeller Diameter Of 90-3500 Mm For Air Temperature Range Of 20-1000 Celsius Degree High Temperature Centrifugal Fan 0 Industrial Centrifugal Fan With And Impeller Diameter Of 90-3500 Mm For Air Temperature Range Of 20-1000 Celsius Degree High Temperature Centrifugal Fan 1 Industrial Centrifugal Fan With And Impeller Diameter Of 90-3500 Mm For Air Temperature Range Of 20-1000 Celsius Degree High Temperature Centrifugal Fan 2
Key Features
Air Temperature
20-1000°C
Material
Cast Iron, Carbon Steel, Stainless Steel
Efficiency
80%-90%
Impeller Diameter
90-3500 mm
Speed
560-2900 rpm
Pressure Range
3000-25425 Pa
Flow Range
1297-83305 m³/h
Applications
  • Cement
  • Industrial boiler
  • Dryer
  • Dust collection
  • Forced draft
  • Fume exhaust
  • General ventilation
  • Incineration
  • Induced draft
  • Power generation
  • Chemical processing
  • Combustion-support
  • Cooling systems
  • Corrosive gas handling
Specification Request
Please advise us the USAGE and following parameters. Our engineering department will recommend the most suitable product for you.
Parameter Value Unit
Air volume/air flow m³/h
Total pressure or static pressure Pa
Medium temperature °C
Voltage V
Frequency Hz
Altitude of operation place m
