High Pressure Double Inlet Centrifugal Fan 380mm-3200mm Impeller Diameter

Forward Curved Double Inlet High Pressure Centrifugal Blower Fan For Dust Exhaust Industry

Forward curved Double inlet high pressure centrifugal blower fan for dust Exhaust industry,these model blower fan are for the gasification of all kinds of fuel quality and smoke prevention and dust control device 20 ~ 35 t/h industrial boiler in design, but the highest temperature should not exceed 300 ℃, must be installed in front of the induced draft fan efficiency shall be not less than 85% of the dust removal device, in order to reduce the flue gas dust content into the fan, the boiler design, all conditions of use, the same performance requirements are the same, Both can be used.

      Key Features

• Impeller diameter: 380~3200 mm
• Speed of mainshaft: 730~1450 rpm
• Pressure range: 653~27860Pa
• Flow range: 3000~955980 m3/h
• Air Temperature: 20~600 Celsius degree

• Material: Cast Iron, Carbon Steel, Stainless Steel.

• Efficiency: 70%-90%

•

     Applications
