Cylinder Free Standing Industrial Axial Fans Easy Move Greenhouse Exhaust Fan

Cement kiln cylinder cooling fan greenhouse exhaust fan exhaust axial fan direct motor a bracket easy to move
Cement kiln cylinder cooling fan is mainly used for cooling and cooling of kiln body when burning cement clinker, and can be used for cooling of other rotary kilns. This device is a mobile air-cooled device.
Ii. Components
X45.25 cement kiln cylinder cooling fan, composed of small car frame, windmill, nozzle. Car frame: welded by Angle steel. It has the advantages of compact structure, beautiful and practical. It plays the role of supporting the fan and air duct, and the wheels together form a parallel moving device.
Iii. Characteristics and Usage
The cement kiln cylinder cooling fan adopts oblique flow fan, which is a low-noise medium-pressure fan. It is an important part of the air cooling device. Fan is composed of cylinder, impeller, motor and other parts. The X45.25 type cement kiln cylinder cooling fan is placed on the laid track, and 14B (140mmX60mmx8mm) channel steel is recommended for the track. The track spacing should be guaranteed to be 720±5mm, not less than 720mm. Fan power requirements are three-phase alternating current, 380V, 50HZ. Equipped transmission line frame or mobile cable. Before operation, check whether the connection parts are tight and remove foreign bodies in the flow channel. Dial the fan impeller, there should be no rubbing phenomenon.

 Key Features

• Impeller diameter: 300~800 mm
• Air flow: 1230~43940 m3/h
• Air pressure: 212~4000 pa
• Temperature: 20℃
• Driving Mode: Direct Drive
