High Temperature Industrial Axial Fans Low Noise Stainless Steel

Cement kiln cylinder cooling fan axial centrifugal fan low noise high efficiency high temperature axial fans

Cement kiln cylinder cooling fan is also called the turn cement cooling axial flow fan, and simplified the cooling fan, plant is rotating simplified flow fan cooling dedicated box, by car, stents, fan, direction adjusting device, the wind, nozzle structure, it is mainly used for cement industry guest simplified body burning cement clinker with dense body cooling, can be used for other rotary cooling, this fan is a portable air cooling Device.
The fan can either move freely or be placed on the laid track. It can be operated by adjusting the blowing Angle. Usually, the height of more than 10 units can play an equal and good cooling effect on the simplified character.
The fan power supply must be three-phase ac, 380V, and 50HZ. Equipped with a dedicated transmission line rack or moving wire.
Before transfer, check whether the connection parts are fastened, and remove foreign bodies in the flow passage. When toggle the impeller of the fan, there should be no probing phenomenon. The temperature of the blowing medium is not more than 60℃, the dust content is not more than 150mg/m3, no debris with a diameter of more than 1mm, no explosive and corrosive property, in order to facilitate the normal work of the fan. If the product is found abnormal in the use process, it should be repaired immediately. In addition, it should be regularly full of dust accumulation, dirt and other impurities in the fan.

 Key Features

Impeller diameter: 400~800 mm

Air flow: 2230~43940 m3/h

Air pressure: 112~2015 pa

Temperature: 20℃

Driving Mode: Direct Drive
