Rotary Kiln Cooling Fan High Capacity Industrial Axial Fans For Large-Scale Ventilation And Exhaust Systems High Efficiency Blower

Rotary Kiln Cooling Fan High Capacity Industrial Axial Fans For Large-Scale Ventilation And Exhaust Systems High Efficiency Blower
Rotary Kiln Cooling Fan High Capacity Industrial Axial Fans For Large-Scale Ventilation And Exhaust Systems High Efficiency Blower
Rotary Kiln Cooling Fan High Capacity Industrial Axial Fans For Large-Scale Ventilation And Exhaust Systems High Efficiency Blower Rotary Kiln Cooling Fan High Capacity Industrial Axial Fans For Large-Scale Ventilation And Exhaust Systems High Efficiency Blower Rotary Kiln Cooling Fan High Capacity Industrial Axial Fans For Large-Scale Ventilation And Exhaust Systems High Efficiency Blower Rotary Kiln Cooling Fan High Capacity Industrial Axial Fans For Large-Scale Ventilation And Exhaust Systems High Efficiency Blower Rotary Kiln Cooling Fan High Capacity Industrial Axial Fans For Large-Scale Ventilation And Exhaust Systems High Efficiency Blower

Large Image :  Rotary Kiln Cooling Fan High Capacity Industrial Axial Fans For Large-Scale Ventilation And Exhaust Systems High Efficiency Blower

Product Details:
Place of Origin: XINXIANG
Brand Name: ZR BLOWER
Certification: CE, ISO 9001
Model Number: ZR-HP SERIES
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: 50-50000
Packaging Details: WOODEN PACKING
Delivery Time: 5-45DAYS
Payment Terms: L/C, D/A, D/P, T/T
Supply Ability: 10000
Contact Now

Rotary Kiln Cooling Fan High Capacity Industrial Axial Fans For Large-Scale Ventilation And Exhaust Systems High Efficiency Blower

Description
Voltage: 220V/380V/440V/480V/660V Blade Material: Stainless Steel,Cast Iron,Steel Plate,Q345 (16Mn) Manganese Steel
Power: 5 - 350KW Warranty: 1 Year
Air Volume: 800 - 90000m3 / H Color: Customer's Requirement
Material: Steel,316L,Carbon Steel /Stainless Steel,Q235 Applications: Cooling Systems
Name: Industrial Axial Flow Fan Certification: CE, ISO 9001
Highlight:

high capacity industrial axial fan

,

rotary kiln cooling fan blower

,

large-scale ventilation exhaust fan

Rotary Kiln Cooling Fan High Capacity Industrial Axial Fans For Large-Scale Ventilation And Exhaust Systems High Efficiency Blower
The axial flow fan for rotary kiln barrel is a specialized axial flow ventilation equipment designed exclusively for the high-temperature calcination scenario of rotary kilns. Its core function is to efficiently deliver combustion-supporting air or cooling air into the kiln. Leveraging the high air flow and low air pressure characteristics of axial flow fans, it adapts to the "long barrel-shaped" structure of rotary kilns and high-temperature operating conditions, ensuring the oxygen supply during the calcination process and the stable temperature of the kiln body.
Its key designs are developed around the needs of rotary kilns:
  • It has strong high-temperature resistance. Core components such as impellers and casings are mostly made of heat-resistant steel (e.g., 310S) or coated with high-temperature-resistant coatings, capable of withstanding the radiant heat of 800-1200℃ at the kiln tail and the erosion of flue gas.
  • It has strong air supply adaptability. The fan installation angle and air supply channel can be customized according to the diameter of the rotary kiln and the position of the calcination zone, ensuring that the air flow direction matches the movement direction of materials in the kiln and realizing the uniform coverage of combustion-supporting air.
  • It has high operational stability. The motor is mostly equipped with a cooling system to avoid overload in high-temperature environments. Meanwhile, the blade design takes into account dust accumulation resistance, reducing the impact of dust in the kiln on fan efficiency.
Rotary Kiln Cooling Fan High Capacity Industrial Axial Fans For Large-Scale Ventilation And Exhaust Systems High Efficiency Blower 0 Rotary Kiln Cooling Fan High Capacity Industrial Axial Fans For Large-Scale Ventilation And Exhaust Systems High Efficiency Blower 1
Key Features
  • Impeller diameter: 90~3500 mm
  • Speed of mainshaft: 560~2900 rpm
  • Pressure range: 30~3000Pa
  • Flow range: 1297~83305 m3/h
  • Air Temperature: 20~1000 Celsius degree
  • Material: Cast Iron, Carbon Steel, Stainless Steel.
  • Efficiency: 70%-90%
Applications
  • Cement
  • Industrial boiler
  • Power generation
  • Chemical processing
  • Combustion-support
  • Cooling systems
  • Corrosive gas
  • Dryer
  • Dust collection
  • Forced draft
  • Fume exhaust
  • General ventilation
  • Incineration
  • Induced draft
Please advise us the USAGE and following Parameter. Our engineering Dept will recommend the most suitable product for you.
Air volume/air flow m3/h
Total pressure or static pressure Pa
Medium temperature ° c
Voltage V
Frequency Hz
Altitude of operation place m
Order details:

Production capacity: 300 sets per month

MOQ: 1 Set

Port: Qingdao, Tianjin, Shanghai port and other ports

Delivery time: 15 days after receiving down payment

Payment: T/T, L/C, D/A, D/P etc.

Price term: FOB, CIF, CFR, DDU, DDP and so on

Rotary Kiln Cooling Fan High Capacity Industrial Axial Fans For Large-Scale Ventilation And Exhaust Systems High Efficiency Blower 2
