High Pressure Centrifugal Fan Blower Forward Curved For Power Generation

High pressure centrifugal exhaust fan high efficiency ac centrifugal fan forward curved centrifugal fan cooling blower

Centrifugal fan has what transmission modes:

A model:
Cantilever type, no bearing, fan impeller is directly mounted on the motor shaft, the speed of the fan is the same as that of the motor. Suitable for small centrifugal fan, compact structure, small body.
B type
Cantilever type, belt transmission structure, belt wheel mounted between the two support bearing housing. Centrifugal fan with variable speed applied to medium and above.
C type:
Cantilever type, belt drive structure, belt wheel mounted on the outside of the two support bearings. Suitable for medium and above centrifugal fan with variable speed, the pulley is more convenient to remove.
D models:
Cantilever type, the transmission structure that uses the coupling to link the main shaft of the ventilator and the motor, the coupling is installed on the outside of the two supporting bearing housing, the speed of the fan is the same as the speed of the motor. It is applied to centrifugal fans above medium size.
F type:
The coupling is used to link the main shaft of the ventilator and the motor, and the two support bearings are installed on both sides of the casing, which is a two-support type, and the coupling is installed on the outside of a bearing seat. It is suitable for the centrifugal fan with double suction or large single suction and the speed is the same as the speed of the motor, and its advantage is that the operation is relatively smooth.

Key Features

• Impeller diameter: 90~3500 mm
• Speed of mainshaft: 560~2900 rpm
• Pressure range: 3000~25425 Pa
• Flow range: 1297~43305 m3/h
• Air Temperature: 20~1000 Celsius degree

• Material: Cast Iron, Carbon Steel, Stainless Steel.

• Efficiency: 70%-90%
