Product Details:
|
| Voltage: | 220V/380V/440V/480V/660V | Blade Material: | Stainless Steel,Cast Iron,Steel Plate,Q345 (16Mn) Manganese Steel |
|---|---|---|---|
| Air Volume: | 800 - 90000m3 / H | Warranty: | 1 Year |
| Color: | Customer's Requirement | Power: | 5 - 350KW |
| Material: | Steel,316L,Carbon Steel /Stainless Steel,Q235 | Type: | Centrifugal Fan,Multi-wings Industrial Centrifugal Exhaust Blower Fan,centrifugal Blower,high Pressure Blower |
| Applications: | Cooling Systems | Name: | Industrial Axial Flow Fan |
| Certification: | CE, ISO 9001 | ||
| High Light: | Forward Curved Centrifugal Fan Blower,Centrifugal Fan Blower 220V,Forward Curved Centrifugal Blower |
||
Installation matters
1. The fan will lie to install shock absorber through the connecting bolt fixed in the fan base, with center high level height adjustment plate to adjust the shock absorber, the fan with the retaining bolt connection on the basis of solid have been welded in sheet metal, such as fan due to reasons such as seismic without shock absorber, will fan the screw hole on the frame and on the basis of embedded bolt connection can be directly.
2. The basic requirements of the horizontal installation of the side wall fan are the same as the horizontal installation, except that the installation bracket is made into the oblique arm support type, and the bracket should have sufficient strength and stiffness. This installation method is not suitable for fans above 10#.
3. The suspension installation firstly connects the shock absorber and the fan with bolts, and the shock absorber is installed symmetrically, arranged on both sides of the center of gravity of the fan, and the fan is directly lifted and inserted into the suspension bracket. The height of the suspension bracket is determined by the user according to the actual spatial distance.
4. vertical installation fan vertical installation method is consistent with the horizontal installation, the fan foundation strength and stiffness requirements are more stringent.
5. The connection between the fan and the pipes at both ends must be flexible joints to isolate vibration and protect the fan.
Debug method
Key Features
Material: Cast Iron, Carbon Steel, Stainless Steel.
Efficiency: 80%-90%
Applications
Please advise us the USAGE and following Parameter.Our engineering Dept will recommend the most suitable product for you.
| Air volume/air flow | m3/h | |
| Total pressure or static pressure | Pa | |
| Medium temperature | °c | |
| Voltage | V | |
| Frequency | Hz | |
| Altitude of operation place | m |
